CH-560HA Full Automatic Double Column |
Feature:
The automatic and semi-automatic dual-column horizontal sawing machine series designed by our company
is incorporated with advantages of many other manufactures, featuring reasonable structure, stable and reliable
performance, and high precision. It is ideal equipment for sawing cutting of medium small lots.
Specification:
Model | CH-280HA | CH-360HA | CH-460HA | CH-560HA | |
Cutting capacity | Round: Φ280mm Quadrate: 350x280mm Bundle cutting: 200x130mm | Round: Φ360mm Rectangular: 360x360mm Bundle cutting: 210x150mm | Round: Φ460mm Rectangular: 460x460mm Bundle cutting: 310x230mm | Round: Φ560mm Rectangular: 560x560mm
| |
Saw blade | speed | 20 – 80 m/min inverter | |||
size | 27x0.9x4110mm | 34x1.1x4420mm | 41x1.3x5450mm | 41x1.3x6200mm | |
guides | Carbide and bearing blade guides | ||||
cleaning | Power wire brush & flood coolant | ||||
tension | hydraulic | ||||
Motor power | Blade | 2.2 kw | 4 kw | 4 kw | 5.5 kw |
hydraulic | 0.75kw | 0.75kw | 0.75kw | 1. 5kw | |
coolant | 0.06kw | 0.06kw | 0.06kw | 0.06kw | |
Multiple feed | 400mm x 9 times | ||||
Work vise | Hydraulic | Hydraulic | Hydraulic | Hydraulic | |
Table height | 1500kgs | 2100kgs | 3500kgs | 3800kgs | |
Machine size | 2200x1900x1700mm | 2500x2200x1750mm | 2850x2200x1900mm | 3400x2200x200mm | |
Standard equipment:
Power blade cleaning brush
Working light
Automatic feed roller
Automatic work height control
One piece of bi-metal saw blade
One set of tools with toolbox
Automatic chip conveyor
Operation manual
NC control (10 set cutting process)
Roller rack 2M long
Hydraulic blade tension
Inverter
Bundle cutting device
Optional equipment:
Roller rack 2M long
Variable vise pressure
